The coverage of a LoRa network depends as much on the building's environment as it does on the distance between the sensors and the gateway. Walls, floors, metal structures, antennas, and the placement of equipment directly affect signal quality.
LoRa is particularly well-suited for building automation due to its long range and low power consumption. However, the advertised range in open terrain cannot be directly applied to a commercial or industrial building.
What is the actual range of LoRa?
In open terrain, with no obstacles and a direct line of sight between devices, LoRa can cover several kilometers. Enless solutions, in particular, can reach over 5 kilometers in open terrain.
Inside a building, the range depends on many factors:
- The distance between the sensor and the gateway
- The number of walls and floors crossed
- The presence of reinforced concrete
- Metal Structures and Cabinets
- The height of the equipment
- The Quality and Orientation of the Antennas
- Noise and Radio Interference
- Receiver sensitivity
Therefore, there is no universal indoor distance. Two buildings of the same size may have very different radio performance.
What obstacles limit LoRa coverage?
Each obstacle attenuates part of the signal. The degree of attenuation depends on the obstacle's thickness, composition, and the angle at which the wave strikes it.
| Type of obstacle | Effect generally observed |
|---|---|
| Lightweight Partition | Low to moderate |
| Brick or cinder block wall | Moderate |
| Thick stone wall | Moderate to strong |
| Reinforced concrete | Strong |
| Metal door or structure | Very strong |
| Metal Electrical Cabinet | Significant risk of jamming |
| Elevator shaft | A very unfavorable environment |
Metal structures are one of the main areas of concern. A closed electrical cabinet can act as a Faraday cage and block a large portion of the signal.
How should I position the gateway or receiver?
A gateway installed in a remote location, in a basement, or behind several metal walls will not be able to take full advantage of LoRa's performance.
Whenever possible, choose a location:
- Relatively central with respect to the sensors
- High enough
- Away from metal obstacles
- Close to the areas that are most difficult to cover
- Accessible for commissioning and maintenance
The geographic center of the building is not necessarily the best location. It is also important to consider the distribution of sensors and critical areas such as boiler rooms, basements, and utility rooms.
Why is antenna placement so important?
The antenna plays a crucial role in the LoRa network's coverage.
A gateway or receiver can be installed in a cabinet BMS, but its antenna must be mounted outside the metal enclosure.
For optimal performance:
- Place the antenna outside the cabinet
- Hold it upright
- Install it as high as possible
- Keep it away from power equipment
- Avoid sticking it to a metal surface
- Check the SMA connector connection
The Enless LoRaWAN gateway and LoRa Easy receivers can be used with the ANT REN SMA LR 868 1000-008 long-range antenna.
See the antenna installation guide for positioning recommendations.
How do you interpret RSSI and SNR?
The quality of a LoRa connection should not be assessed based on a single metric.
The CISO
RSSI represents the strength of the received signal. It is expressed in dBm and is typically a negative value.
The closer the value is to zero, the stronger the signal. An RSSI of −70 dBm is therefore better than an RSSI of −110 dBm.
For Easy Enless LoRa receivers, the documentation uses the following reference numbers:
- Signal is good up to −105 dBm
- Valid signal range: −106 to −112 dBm
- Weak signal below −112 dBm
These reference values are specific to LoRa Easy receivers. In LoRaWAN, acceptable levels vary depending on the spreading factor used, among other factors.
The SNR
SNR represents the ratio of the desired signal to radio noise. A signal may be strong but can be disrupted by motors, power supplies, or other transmissions.
Thanks to LoRa modulation, a frame can sometimes be decoded even with a negative SNR. It is therefore best to analyze the following together:
- The CISO
- The SNR
- The Spreading Factor
- The Frequency of Messages
- The number of lost frames
A single received frame is not enough to definitively validate a location.
How do you test the coverage of a LoRa network?
1. Identify critical areas
Locate the following on a map:
- The proposed location of the gateway
- Sensor Locations
- The different floors
- Concrete walls and slabs
- Metal Structures
- Basements and utility rooms
Start testing at the locations with the most challenging radio path.
2. Temporarily install the gateway and the antenna
Position the gateway and its antenna in their final locations. The antenna must already be installed outside the cabinet and in a vertical position.
3. Test the sensors in their actual locations
Place each sensor where it will be installed. On Enless sensors equipped with a push button, a brief press immediately triggers the transmission of a test frame.
4. Monitor multiple transmissions
Check to see if you have received several messages, and note the following:
- The CISO
- The SNR
- The Spreading Factor
- Radio Quality
- The Frequency of the Rides
If possible, conduct the tests with the doors and cabinets closed and the technical equipment running.
How can I improve poor LoRa coverage?
Perform the following steps in this order:
- Check the antenna connection
- Pull the antenna out of the metal cabinet
- Place the antenna higher
- Keep it away from power equipment
- Try a new career path
- Move the gateway or receiver
- Add reception equipment if necessary
This method prevents the network from being oversized, when sometimes simply moving the antenna can solve the problem.
Expanding LoRaWAN Coverage
In a LoRaWAN network, multiple gateways can receive messages from the same sensor.
If an area remains poorly covered after optimizing the antenna, it is possible to add a second gateway. A typical LoRaWAN architecture does not rely on signal repeaters.
The Enless LoRaWAN gateway can manage up to 500 Enless or third-party LoRaWAN sensors. It includes its own LoRa Network Server and makes the data available to the BMS in Modbus or BACnet format.
Expanding Coverage with LoRa Easy
LoRa Easy is Enless's proprietary protocol based on LoRa technology.
In this architecture, a LoRa Easy signal repeater can be placed halfway between the sensors and the receiver. It automatically repeats the received frames without requiring any configuration.
However, it is important to note that the repeater:
- Works only with Enless sensors in LoRa Easy mode
- Is not compatible with LoRaWAN
- Must be placed in an area where it receives a good signal from the sensors
- Must be kept away from metal objects
- Add radio traffic to the installation
Enless therefore recommends limiting the number of repeaters and starting by optimizing the antenna and receiver.
See the RX REPEATER installation guide for detailed instructions.
Frequently Asked Questions About LoRa Coverage
How far can LoRa reach inside a building?
There is no guaranteed indoor range. Coverage depends on the materials, the number of floors, the antenna, the gateway, and radio interference.
Is a range of 5 kilometers possible indoors?
This range applies to open-field conditions. It cannot be guaranteed through the walls and floors of a building.
Where should a LoRa antenna be installed?
The antenna must be mounted high up, in a vertical position, outside metal cabinets, and away from power equipment.
Can you use a repeater with LoRaWAN?
The Enless repeater operates exclusively in LoRa Easy mode. To expand a LoRaWAN network, you must optimize the deployment or add a gateway.
How do I permanently confirm my coverage?
Test multiple transmissions from each critical location and monitor the RSSI, SNR, and message consistency under real-world conditions within the building.
Improve the reliability of your LoRa network coverage
LoRa's long range is a major advantage for the BMS, but it does not eliminate the need for a systematic deployment.
Reliable coverage is based on four principles: anticipating obstacles, positioning antennas correctly, testing critical points, and maintaining sufficient radio margin.
